پارو آنالایز ایسکرا ISKRA MC770

Evaluation of the electricity supply quality in compliance with SIST EN 50160

Measurements of instantaneous values ​​of more than 140 quantities (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy, energy cost by tariffs, etc.)

Accuracy class 0.5 (optional 0.2)

Recording up to 32 measurands and 32 alarms in the internal memory (8 MB flash)

RS 232/RS 485 communication up to 115,200 bit/s or Ethernet/USB communication

MODBUS and DNP3 communication protocol Up to 4 inputs or outputs (analogue outputs, analogue inputs, pulse outputs, alarm outputs, tariff inputs, digital inputs)

Universal or AC power supply Automatic range of nominal current and voltage (max. 12.5 A and 750 V)

Adjustable tariff clock, display of electric energy consumption in optional currency Multilingual Support

User-friendly PC MiQen software
